• 2-spoke steering wheel
• Black vinyl floor covering
• Cab-back panel stowage
• Cargo lamp
• Cigar lighter/pwr outlet
• Color-keyed full length door trim panels w/armrests
• Dash insulation liner
• Day/night rearview mirror
• Dual-opening retractable cup holder
• Electronic AM/FM stereo radio w/cassette
• HD vinyl 40/20/40 double split-back bench seats w/rear flip-type bench seat
• Hood release in cab
• Instrument cluster-inc: 120 MPH speedometer, tachometer
• Passenger assist handle

• (4) bright trim rings/hub center
• (5) 16" x 7.5" steel wheels
• 117-amp alternator
• 3.54 axle ratio
• 35 gallon fuel tank
• 600-amp maintenance-free battery
• 8800# GVWR (5200 front/6200 rear), springs (5200 front/6200 rear), axles (5200 front/6200 rear)
• Conventional spare tire w/winch type carrier
• Four wheel drive
• Front stabilizer bar
• HD front/rear shock absorbers
• LT245/75R16E all-season SBR BSW tires
• NV241 2-speed transfer case w/shift-on-the-fly auto hubs
• Pwr 4-wheel anti-lock disc brakes
• Solid front axle w/link-coil suspension
• Solid rear axle w/longitudinal leaf springs
• Variable assist pwr steering

• Driver/front passenger "Next Generation" airbags w/passenger on/off switch
• Dual note electric horn
• Front shoulder belt height adjusters
• Rear-wheel anti-lock brakes
• Side-guard door beams

5.9L (359) HO I6 CUMMINS TURBO DIESEL ENGINE

• HD service group
• diesel message center (w/low fuel/low oil/water in fuel/wait to start/brakes/anti-lock brake warning lights)
• "Cummins Turbo Diesel" nameplates
• diesel sound insulation on inner dash/cowl/floor pads
• engine block heater

• Four Wheel Drive
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Steel Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Third Passenger Door
• Fourth Passenger Door
• Vinyl Seats
• Split Bench Seat
• AM/FM Stereo
• Cassette
• Power Outlet
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• ABS

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.5 x 1.50
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 19.4
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 71.7
• Ext'd Cab Cargo Volume (ft³): 48.5
• Tailgate Width (in): 64.3
• Cooling System
• Total Cooling System Capacity (qts): 24.0
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 117
• Exterior Dimensions
• Cab to Axle (in): 55.7
• Cab to End of Frame (in): 99.7
• Front Bumper to Back of Cab (in): 136.9
• Ground Clearance, Front (in): 15.9
• Ground Clearance, Rear (in): 8.2
• Ground to Top of Load Floor (in): 37.2
• Height, Overall (in): 76.9
• Length, Overall w/o rear bumper (in): 240.1
• Overhang, Front (in): 39.0
• Overhang, Rear w/o bumper (in): 47.5
• Wheelbase (in): 154.7
• Width, Max w/o mirrors (in): 79.3
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 35.0
• Fuel Tank Location: Inboard Frame Rails
• Interior Dimensions
• Front Head Room (in): 40.2
• Front Hip Room (in): 63.6
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 66.5
• Passenger Capacity: 6
• Second Head Room (in): 39.4
• Second Hip Room (in): 65.1
• Second Leg Room (in): 33.2
• Second Shoulder Room (in): 67.1
• Steering
• Steering Type: Pwr
• Turning Diameter - Curb to Curb (ft): 51.3
• Summary
• Body Code: 155" WB
• Body Style: Quad Cab 8'
• Vehicle Name: Dodge Ram 2500
• Suspension
• Axle Capacity - Front (lbs): 5200
• Axle Capacity - Rear (lbs): 7500
• Axle Ratio (:1) - Front: 3.55
• Axle Ratio (:1) - Rear: 3.55
• Axle Type - Front: Hypoid
• Axle Type - Rear: Full-Floating
• Shock Absorber Diameter - Front (mm): 35.1
• Shock Absorber Diameter - Rear (mm): 35.1
• Spring Capacity - Front (lbs): 5200
• Spring Capacity - Rear (lbs): 6500
• Suspension Type - Front: Coil
• Suspension Type - Rear: Leaf
• Tires
• Front Tire Capacity (lbs): 3040
• Front Tire Order Code: TYD
• Front Tire Size: LT245/75R16E
• Rear Tire Capacity (lbs): 3040
• Rear Tire Order Code: TYD
• Rear Tire Size: LT245/75R16E
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Capacity (lbs): 3040
• Spare Tire Order Code: TYD
• Spare Tire Size: LT245/75R16E
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 900
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10,000
• Weight Information
• Curb Weight - Front (lbs): 3070
• Curb Weight - Rear (lbs): 2140
• Gross Axle Wt Rating - Front (lbs): 4500
• Gross Axle Wt Rating - Rear (lbs): 6200
• Gross Combined Wt Rating (lbs): 20,000
• Gross Vehicle Weight Rating Cap (lbs): 8800
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 16 x 7.5
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 16 x 7.5
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 16 x 6.5
